Product : 3G HD SDI Galvanic video ground path isolator, In Line / Tubular Model
Model No. : L3GGI 01
Overview
The L3GGI 01 is a galvanic signal and gound path isolator for use with 3G HD, SD & SDI video signals. They are built in cylindrical "barrel" style enclosures and fitted with a BNC connector at each end and isolate both the signal and ground paths.
Also available in panel mount version with flanges
Features
Bandwith: 0.5MHz to 3.0GHz
DC Breakdown voltage: 100 volts minimum
Input and output impedance: 75 ohms
Return loss: >20dB
Dimensions: 30 x 20 (l x diameter) mm
Weight: 36g
Description / Details
Our LEN ground isolators use broadband high-pass filters to provide isolation of DC currents between two pieces of equipment, whilst permitting the full bandwidth of the SDI signal to pass, thus avoiding problems of signal distortion and operator shocks caused by a voltage difference. This method out-performs broadband transformers for SDI signals. Both signal and ground paths between equipment are isolated, there is no distortion of the signal. They are also suitable for ASI format.
